Specifications
| EDISON |
|
| Seats: |
6 adults |
| Dimensions:* |
214 cm x 214 cm x 92 cm |
| Dry Weight: |
344 kg |
| Total Filled Weight: |
2,046 kg |
| Average Spa Volume: |
1,325 liters |
| Jet Pumps: |
Pump 1 North America 2-speed/2.5 hp continuous |
| |
Pump 21 North America 1-speed/2.5 hp continuous |
| Total Jets: |
35 |
| DVR jets: |
4 |
| DX Jets: |
4 |
| DL Jets: |
17 |
| DXL Jets: |
7 |
| DXT Jets: |
2 |
| DVX Jets: |
1 |
| Air Control/Massage Selectors: |
3 Controls |
| Water Purification System: |
CLEARRAY® |
| Filter: |
50 sq ft. |
| Circulation Pump: |
2 jet pumps |
| Electrical Requirements: |
North America (60 Hz): 240 VAC @ 40A, 50A or 60A |
| |
Export (50 Hz): 230 VAC @ 20A, 30A or 40A |
| Lighting: |
Multicolor LED Lighting |
| Stainless Steel Jet Trim: |
35 with stainless steel trim |
| Headrests: |
3 |
| Heater: |
5.5 kW Low Flow |
| Water Feature: |
1 Cascading Waterfall |
| Stereo: |
Optional BLUEWAVE™ Spa Stereo System |
| Shell Colors: |
Celestite, Platinum, Oyster, Sahara, Sand, Copper Sand, Monaco, Titanium, Caribbean Surf, Midnight |
| Cabinetry: |
Coastal, Mahogany, Autumn Walnut |
Estimated monthly cost is based on CEC test protocol for standby power consumption only. Test results measured in a controlled environment based on a kilowatt rate per hour of $0.24 (typical-2015-NZ-pricing) and rounded to the nearest dollar. Local and future energy rates, local conditions and individual use will alter these estimated monthly costs. For complete CEC test protocol and
results visit energy.ca.gov. Spa Temperature 101°F / 38°C.
* BHP (brake horsepower) is a maximum value measured by the motor manufacturer with no pump installed.
** Heater warranty varies outside North America Dimensions, capacities and weights are approximate.
Specifications are subject to change without notice.
